01
1/1 View011 Title : IMG1
---------------------------
Instrument : JCM-5700
Volt : 15.00 kV
Mag. : x 3,000
Date : 2016/10/15
Pixel : 1024 x 768 Acquisition Parameter
Instrument : JCM-5700
Acc. Voltage : 15.0 kV
Probe Current: 0.79591 nA
PHA mode : T3
Real Time : 65.20 sec
Live Time : 53.41 sec
Dead Time : 17 %
Counting Rate: 3804 cps
Energy Range : 0 - 20 keV ZAF Method Standardless Quantitative Analysis(Oxide)
Fitting Coefficient : 0.1876
Total Oxide : 24.0
Element (keV) Mass% Error% Mol% Compound Mass% Cation K
C K 0.277 4.98 0.23 22.40 C 4.98 0.00 1.7328
O 45.15
Na K 1.041 2.58 0.26 3.03 Na2O 3.48 0.95 4.6018
Mg K 1.253 1.82 0.28 4.03 MgO 3.01 0.64 3.0317
Al K 1.486 9.80 0.32 9.80 Al2O3 18.51 3.09 18.3785
Si K 1.739 25.18 0.41 48.40 SiO2 53.87 7.63 49.6993
S K 2.307 2.35 0.49 3.95 SO3 5.86 0.62 4.9204
Cl K 2.621 0.77 0.23 1.18 Cl 0.77 0.00 1.7010
K K 3.312 0.29 0.39 0.20 K2O 0.34 0.06 0.6699
Ca K 3.690 1.04 0.55 1.40 CaO 1.46 0.22 2.5916
Fe K 6.398 5.65 1.43 5.46 FeO 7.26 0.86 11.9047
Ba L 4.464 0.40 1.40 0.16 BaO 0.44 0.02 0.7685
Total 100.00 100.00 100.00 14.09<br>
